Automatic digital tear tester, suitable for testing specimens within a very wide tear range, like textiles, paper, leather, plastic,
non-woven and other materials
The only ELMENDORF tear tester on the market able to automatically perform the following operations:
Suitable for all kinds of textiles, technical and protective fabrics, as well as for paper, cardboard, natural and artificial leather, plastic, nonwoven and other materials.
Model with a high laceration capacity, ranging from 1600 to 30.000 cN.
Pendulum complete with additional check weights, supplied as standard with the instrument.
Equipped with alphanumeric keyboard and digital reader for the measurement of the laceration values that can be printed or transferred to a PC through a RS 232 serial port.
Instrument fully protected and complying with the strictest EU safety norms.
Optional:
– Mini thermal printer,
INTERNATIONAL STANDARDS:
Textile – according to: UNI EN ISO 13937-1, UNI EN ISO 4674-2 (coated fabrics),ASTM D1424, ASTM D751 (coated fabrics), UNI EN ISO 1974, M&S P29
Plastic – according to: UNI EN ISO 6383-2
Paper – according to: TAPPI T414, UNI EN ISO 1974
Other reference Standards: GB/3917.1, FZ/T 60006, FZ/T 75001, GB/T 455, JIS L1096, JIS K7128.2
Officially approved by Marks & Spencer.
Power supply: 115 up to 230 Vac, 50/60 Hz, single-phase
Weight: 66 kg
Dimensions: (L) 510 x (W) 700 x (H) 630 mm
